New Design 500W 520W 540W 550W Shingle Style Solar Panels Factory China

All Full Black Shingled Mono Solar Panel
All Full Black Shingled Mono Solar Module
Shingled Glass Solar Panel Factory
All Full Black Solar Shingled Panel Manufacturer
Solar Shingled Panel For Home
500W 520W 530W 540W 550W Shingled Mono Solar Panel

New Design 500W 520W 540W 550W Shingle Style Solar Panels Factory China

Using Shingled Solar Panel Technology Hidden busbar, increasing the front lighting area of the solar panel, improving the power and work efficiency of the solar panel

  • Item NO: 550W Shingled
  • MOQ: 10
  • Shipping Port: Guangzhou/Shenzhen, China
  • Original Region: China
  • Lead Time: About 15 working days
  • Warranty: 25 Years
  • Solar Cell Mono Cell: 210*35
  • Efficiency: > 20.34%
  • Certification: EST, UL, CE
  • Panel Size: 2075*1303*35MM
Get A Quote Download
New Technology Shingled Solar Panel High Efficiency Monocrystalline Silicon Solar Modules
Advantages:
1. 360 Monocrystalline Cells 2*(6*30) Cells, Higher Efficiency
2. High Output Power, Using PERC Battery Structure Technology (Low Resistance Characteristics), Output Power Of 248pcs Monocrystalline Cells Reaches Max 350W (Highest Conversion Efficiency To 21.75%)
3. Low Light Performance, Using Excellent Glass And Texture Surface Making Of Solar Cell, Outstanding Performance Can Be Obtained In Low Light Condition.
4. Adaptability Of Harsh Environment, Corrosion Tests Have Certified In High Salt Fog And High Ammonia Environment.
5. Junction Box Certified According To IEC 62790, IP 67 Approved, 3 By Pass Diodes
6. Glass High Transmission, Low Iron, Tempered, ARC, Transparent, 3.2 MM
7. Mechanical Load Test: 5400Pa
8. Front Glass: 3.2MM Coated Tempered Glass
9. Frame: Anodized Aluminium Alloy
10. Junction Box: Ip68 Rated (3 By Pass Diodes)
11. Output Cables:4.0MM 2, 300MM (+) / 400MM (-), Length Can Be Customized.
12. Connectors: MC4 Compa

What is Shingled Cell Technology?

Conventional solar modules are made up of a number of solar cells electrically connected using metallic busbars. The solar cells on conventional solar modules have gaps around them and busbars typically cross over the cells to link them together. Shingled solar modules have layers of solar cells which touch each other and electrically connected using an electrically conductive adhesive (ECA). This eliminates the need for metallic busbars. This method means there are no gaps between the solar cells increasing the surface area of the silicon cells in the solar module. Plus there are no busbars covering the cells which reduce the light on the solar cells. This improves the electrical and mechanical performance and the aesthetics of the solar module.

Model FGETS40-55PH FGETS40-55PH FGETS40-60PH FGETS40-60PH FGETS40-60PH FGETS40-60PH
Electrical Characteristics
　 STC NOCT STC NOCT STC NOCT STC NOCT STC NOCT STC NOCT
Maximum Power(Pmax) 510Wp 391Wp 520Wp 399Wp 540Wp 414Wp 550Wp 422Wp 560Wp 429Wp 570Wp 437Wp
Maximum Power Voltage(Vmpp) 37.62V 35.86V 37.62V 35.86V 34.20V 32.60V 34.20V 32.60V 34.20V 32.60V 34.20V 32.60V
Maximum Power Current(Impp) 13.56A 10.92A 13.82A 11.13A 15.79A 12.71A 16.08A 12.94A 16.37A 13.18A 16.67A 13.42A
Open Circuit Voltage (Voc) 45.75V 43.63V 45.75V 43.63V 41.59V 39.66V 41.59V 39.66V 41.59V 39.66V 41.59V 39.66V
Short Circuit Current(Isc) 14.56A 11.53A 14.84A 11.75A 16.96A 13.43A 17.27A 13.68A 17.58A 13.92A 17.90A 14.17A
Power Tolerance(Positive) 3% 3% 3% 3% 3% 3%
Module Efficiency  STC 20.64% 21.05% 19.97% 20.34% 20.71% 21.08%
Operating Temperature Range -40°C to +85°C
Maximum System Voltage 1500V
Series Fuse Rating 15A 25A
Temperature Coefficient of Pmax -0.40%/°C
Temperature Coefficient of Voc -0.30%/°C
Temperature Coefficient of Isc 0.05%/°C
Nominal Operating Cell Temperature(NOCT) 45±2°C
Mechanical Characteristics
Cell Type Monocrystalline shingled 210×210 mm
Cell Number 2*(5*33) 2*(5*33) 2*(6*30) 2*(6*30) 2*(6*30) 2*(6*30)
Dimensions (mm) 2275×1086×35 2275×1086×35 2075×1303×35 2075×1303×35 2075×1303×35 2075×1303×35
Weight(Kgs) 28.96 28.96 31.69 31.69 31.69 31.69
Front Glass 3.2 mm,High Transmission,Low lron,Tempered Glass
Frame Type Anodized Aluminium Alloy
Junction Box Protection Class IP 67 Rated
Connector Type MC4
Output Cables 4.0mm²,Length: 1200 mm

Full Black Solar Mono Shingled Panels 210W 230W

Full Pine-Sol All Black Frame 500watt 500 550W 600W 600 700 W 1000W Solar Monocrystalline Photovoltaic Panels
Full Pine-Sol All Black Frame 500watt 500 550W 600W 600 700 W 1000W Solar Monocrystalline Photovoltaic Panels
Full Pine-Sol All Black Frame 500watt 500 550W 600W 600 700 W 1000W Solar Monocrystalline Photovoltaic Panels
good quality solar panels
Packaging process:
Solar Panel Corner Protection→Independent Cardboard Box Packaging→Pallet→Wooden Box→PET Plastic Steel Packaging Belt→PE Winding Film
Full Pine-Sol All Black Frame 500watt 500 550W 600W 600 700 W 1000W Solar Monocrystalline Photovoltaic Panels

Product Size: 2075*1303*35mm

Package: 32pcs/Pallet: 18Pallets/40HQ

About FGET



Future Green Techonology is committed to creating a green future.

Rooting ourselves in the new energy industry for decade, we manufacturehigh quality solar panel and battery and win high reputation from hundredscustomers globally.

We also have over 100 long-term partners around the world. We sell high-quality batteries and solar panels, and also customize solar panel systems and solar power stations for our customers who need them. If you also want to customize a solar panel system, you can submit your daily electricity consumption requirements below, and we will immediately develop a detailed energy solution for you.

Support Factory About Future Green



Q1: How to choose the right Panel?
A1: Tell us your demand, then our sales will recommend a suitable panel for you.


Q2: What's the difference between Mono and Poly panels?
A2: Monocrystalline solar panels have the highest efficiency rates since they are made out of the highest-grade silicon. The process used to make polycrystalline silicon is simpler and costs less. The amount of waste silicon is less compared to monocrystalline.

Q3: How about the delivery time?
A3: 7 days for sample; 15 days for bulk order.

Q4: What is the warranty for solar panels?
A4: 5 years warranty on FGET-Solar product.

Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem solve easily.
