Adopting 182MM Multi Gate (MBB) Monocrystalline Half Cut PERC Cells Technology For High Power Solar Cells, Higher Component Power Effectively Reduces System BOS Costs
|
MODULE Plus
|
FG 530 M
|
FG 535 M
|
FG 540 M
|
FG 545 M
|
FG 550 M
|
FG 555 M
|
||
|
Standard Test Conditions STC: 1000 W/m2 - AM 1.5 - 25 °C - tolerance: Pmax (±3%), Voc (±4%), Isc (±5%)
|
||||||||
|
Module power (Pmax)
|
W
|
530
|
535
|
540
|
545
|
550
|
555
|
|
|
Open circuit voltage (Voc)
|
V
|
49.36
|
49.51
|
49.66
|
49.81
|
49.96
|
50.11
|
|
|
Short circuit current (Isc)
|
A
|
13.63
|
13.7
|
13.77
|
13.84
|
13.91
|
13.98
|
|
|
Maximum power voltage (Vmpp)
|
V
|
41.48
|
41.64
|
41.8
|
41.96
|
42.12
|
42.27
|
|
|
Maximum power current (Impp)
|
A
|
12.78
|
12.85
|
12.92
|
12.99
|
13.06
|
13.13
|
|
|
Module efficiency
|
%
|
20.51
|
20.70
|
20.89
|
21.09
|
21.28
|
21.48
|
|
|
Nominal Module Operating Temperature NMOT: 800 W/m2 - T=45 °C - AM 1.5
|
||||||||
|
Module power (Pmax)
|
W
|
400
|
404
|
407
|
411
|
415
|
419
|
|
|
Open circuit voltage (Voc)
|
V
|
46.28
|
46.41
|
46.53
|
46.65
|
46.78
|
46.91
|
|
|
Short circuit voltage (Isc)
|
A
|
10.97
|
11.01
|
11.05
|
11.09
|
11.13
|
11.17
|
|
|
Maximum power voltage (Vmpp)
|
V
|
38.65
|
38.89
|
39.03
|
39.26
|
39.49
|
39.72
|
|
|
Maximum power current (Impp)
|
A
|
10.35
|
10.39
|
10.43
|
10.47
|
10.51
|
10.55
|
|
Product Size: 2279*1134*35mm
About FGET
Future Green Techonology is committed to creating a green future.
Rooting ourselves in the new energy industry for decade, we manufacturehigh quality solar panel and battery and win high reputation from hundredscustomers globally.
We also have over 100 long-term partners around the world. We sell high-quality batteries and solar panels, and also customize solar panel systems and solar power stations for our customers who need them. If you also want to customize a solar panel system, you can submit your daily electricity consumption requirements below, and we will immediately develop a detailed energy solution for you.
Q1: How to choose the right Panel?
A1: Tell us your demand, then our sales will recommend a suitable panel for you.
Adopting 182MM Multi Gate (MBB) Monocrystalline Half Cut PERC Cells Technology For High Power Solar Cells, Higher Component Power Effectively Reduces System BOS Costs Item No: FG550M Color: Black Min Order: 10 PCS Voltage: 50.11V Module Efficiency(%): 21.48% Dimemsions: 2279*1134*35MM Weight: 28.2KG Packing Number: 31Pcs/Pallet Packing Volume: 3.372CBM/Pallent 40'HQ Container: 620PCS
Learn More
FGET,Flexible, and can be properly bent to use a wider range of applications.High conversion efficiency, good output efficiency, low light effect,light weight, easy to carry,easy installation,strong applicability.With SUNPOWER chip, can be used for car ,caravan,home, boat, motorcycle, etc. Item No:FL-205W/36V Size :1840*670*3mm Weight: 3.15kg Maximum power:205W Panel Efficiency:21-22.5% Min order:10 pcs Lead time : 15days OEM:Available Original Region:China Solar cell :A-grade
Learn More
* Solar Cell: Made of Grade A PERC 9BB monocrystalline solar cells. * Premium EFTE Film – This film features superior light transmission and weather resistant performance. * Shade tolerant. * Tabletop: Durable fiberglass tabletop with better heat dissipation and heat resistant PET/TPT tabletop. * Ultra-thin: only 3mm thick. * Installation: can be fixed with adhesive, grommets, zip ties or Velcro. * Net Weight:2.5 kg. * Back sheet: black fiberglass* J-Box: IP 68 rated with 90cm/3ft cables. * WiFi Real time monitoring. * High efficiency up to 99% * Come with built-in WIFI module, so that it can communicate with router directly * Waterproof IP65，10 years warranty
Learn More
Photovoltaic glass curtain wall products can be widely used in building shading systems, building curtain walls, photovoltaic roofs, photovoltaic doors and windows and other photovoltaic power generation.High quality,strong applicability,good output efficiency, low light effect,etc. Item No:FL-55W/18V Size :580*540*25mm Weight:2.9kg Min order:10 pcs Lead time : 15days OEM:Available Original Region:China Maximum power:55W Panel Efficiency:21-22.5% Soalr cell :A-grad
Learn More
Photovoltaic glass curtain wall products can be widely used in building shading systems, building curtain walls, photovoltaic roofs, photovoltaic doors and windows and other photovoltaic power generation.High quality,strong applicability,good output efficiency, low light effect,etc. Item No:FL-160W/18V Size :1100*765*30mm Weight:9.2kg Min order:10 pcs Lead time : 15days OEM:Available Original Region:China Maximum power:160W Panel Efficiency:21-22.5% Soalr cell :A-grad
Learn More
Photovoltaic glass curtain wall products can be widely used in building shading systems, building curtain walls, photovoltaic roofs, photovoltaic doors and windows and other photovoltaic power generation.High quality,strong applicability,good output efficiency, low light effect,etc. Item No:Sh-250W-02 Size :1080*1080*35mm Weight:18.27kg Min order:10 pcs Lead time : 15days OEM:Available Original Region:China Maximum power:250W Panel Efficiency:21-22.5% Soalr cell :A-grad
Learn More
Photovoltaic glass curtain wall products can be widely used in building shading systems, building curtain walls, photovoltaic roofs, photovoltaic doors and windows and other photovoltaic power generation.High quality,strong applicability,good output efficiency, low light effect,etc. Item No:Sh-360W-01 Size :1730*1020*35MM Weight:19.41kg Min order:10 pcs Lead time : 15days OEM:Available Original Region:China Maximum power:360W Panel Efficiency:21-22.5% Soalr cell :A-grad
Learn More
Photovoltaic glass curtain wall products can be widely used in building shading systems, building curtain walls, photovoltaic roofs, photovoltaic doors and windows and other photovoltaic power generation.High quality,strong applicability,good output efficiency, low light effect,etc. Item No:Sh-470w-01 Size :2148*1020*35mm Weight:24.1kg Min order:10 pcs Lead time : 15days OEM:Available Original Region:China Maximum power:470W Panel Efficiency:21-22.5% Soalr cell :A-grad
Learn More
