Clean energy,High conversion efficiency, good output efficiency, low light effect,light weight, easy to carry, perfect funcation,High-quality materials,strong applicability.With SUNPOWER chip, can be used for car,caravan,home, boat, motorcycle,camping,trailer,yacht,etc.
Specification
| Electrical Characteristics | |
| Product code | FL-50W/18V |
| Maximum power(Pmax) | 50W |
| Voltage at Pmax(Vmp) | 18.8 |
| Current at Pmax(Imp) | 3.19 |
| Open-circuit voltage(Voc)23.27 | 23.27 |
| Short -circuit current(Isc) | 3.41 |
| Power temperature coefficient | -0.38%/℃ |
| Voltage temperature coefficient | -0.27%/℃ |
| Cirrent temperature coefficient | +0.05%/℃ |
| Cells Efficiency(%) | 23.70% |
| The maximum system voltage | 45VDC(IEC) |
| Output power tolerance | ±3% |
| Cells | USA A grade solar cell |
| No.of cells and connections Module dimension | 36(4X9) |
| Weight | 585*450*3mm |
| Certification |
This solar panel combines high efficiency (PERC) monocrystalline solar cells with half-cut cell technology to improve electrical performance and power generation efficiency. This panel comes with pre-drilled mounting holes, solar connectors, and a junction box that allows easy and fast installation.]
It works with most curved surfaces as it can be bent within 240 degrees.
Presenting an all-black glare-free appearance.
This Renogy Solar Panel can provide an average of 500 Watt-hours of electricity per day (depending on sun availability).
It offers 5-year material and workmanship warranty and has passed the CE test.
This solar panel frame features a lightweight substrate and laminate, perfect for outdoor applications.
--------------占位---------------
Withstand up to 5400 Pa of heavy snow load and up to 2400 Pa of high wind load.
Provide excellent durability in a harsh environment.
--------------占位---------------
When there is no sun exposure, the diode prevents reverse current flow from the battery to the solar panels, to avoid current damage to your solar panels.
This Renogy solar panel comes with pre-drilled holes for quick installation. Besides, it can also be bonded to the surface by using silicone adhesive or velcro.
The solar connector cables are 2.3 feet long without worrying about length limitations.
The IP67 rated waterproof junction box and solar connectors ensure that water and dust will not enter during extended outdoor use.
Cables attached on the back with Solar Connectors are ready for connection and extension.
50W Flexible Solar Mono Photo voltaic Module
We support custom product packing accroing to your needs
Wooden Box Packing ,Pallet Packing ,Carton packing
About us
Future Green Technology is
committed to creating a green future
Rooting ourselves in the new energy industry for decade,we manufacture high quality
solar panel and battery and win high reputation from hundreds customers globally
Flexible, and can be properly bent to use a wider range of applications.High conversion efficiency, good output efficiency, low light effect,light weight, easy to carry, strong applicability. With SUNPOWER chip, can be used for car ,home, boat, motorcycle, etc. Item No: FGET-100W-F Size :1060*520*3mm Weight:2.34kg Min order:10 pcs Lead time : 15days OEM:Available Original Region:China Maximum power:18.2 Panel Efficiency:23.7% Soalr cell :A-grade
Learn More
Flexible, and can be properly bent to use a wider range of applications.High conversion efficiency, good output efficiency, low light effect,light weight, easy to carry, strong applicability. With SUNPOWER chip, can be used for car ,home, boat, motorcycle, etc. Item No:FL-200W/36V Size :1840*670*3mm Weight: 3.15kg Maximum power:200W Panel Efficiency:21-22.5% Min order:10 pcs Lead time : 15days OEM:Available Original Region:China Solar cell :A-grade
Learn More
Clean energy,High conversion efficiency, good output efficiency, low light effect,light weight, easy to carry, perfect funcation,High-quality materials,strong applicability.With SUNPOWER chip, can be used for car,caravan,home, boat, motorcycle,camping,trailer,yacht,etc. Item No: FL50W /18V Size : 585*450*3mm Min order:10 pcs Maximum power:50W Panel Efficiency:23.70% OEM:Available Soalr cell :A-grade Original Region:China Lead time : 15days
Learn More
Flexible, and can be properly bent to use a wider range of applications.High conversion efficiency, good output efficiency, low light effect,light weight, easy to carry, strong applicability. With SUNPOWER chip, can be used for car ,home, boat, motorcycle, etc. 170W Powerfully Flexible 19.2% Maximum Efficiency 360℃ Bendable Item NO:170W Flexible Color:Black PriceRange:101~999999/$75 PriceRange:11~100/$78 PriceRange:1~10/$80 Min order:1 Original Region:China Lead Time:15 days Sample:Not free
Learn More
Flexible, and can be properly bent to use a wider range of applications.High conversion efficiency, good output efficiency, low light effect,light weight, easy to carry, strong applicability. With SUNPOWER chip, can be used for car ,home, boat, motorcycle, etc. Item No:FL-150W/18V Size :1480*670*3mm Weight: 3.15kg Min order:10 pcs Lead time : 15days OEM:Available Original Region:China Maximum power:19.2 Panel Efficiency:21-22.5% Soalr cell :A-grade
Learn More
Flexible, and can be properly bent to use a wider range of applications.High conversion efficiency, good output efficiency, low light effect,light weight, easy to carry, strong applicability. With SUNPOWER chip, can be used for car ,home, boat, motorcycle, etc. Item No:FL-80W/18V Size :725×585×3mm Weight: 2kg Min order:10 pcs Lead time : 15days OEM:Available Original Region:China Maximum power:18.8 Panel Efficiency:21-22.5% Soalr cell :A-grade
Learn More
Flexible, and can be properly bent to use a wider range of applications.High conversion efficiency, good output efficiency, low light effect,light weight, easy to carry, strong applicability. With SUNPOWER chip, can be used for car ,home, boat, motorcycle, etc. Item No:FL240W/18V Size :1530×765×3 Maximum power:240W Panel Efficiency:21-22.5% Weight: 4kg Min order:10 pcs Solar cell :A-grade OEM:Available Original Region:China Lead time : 15days
Learn More
Flexible, and can be properly bent to use a wider range of applications.High conversion efficiency, good output efficiency, low light effect,light weight, easy to carry, strong applicability. With SUNPOWER chip, can be used for car ,home, boat, motorcycle, etc. Item No:FL-180W/18V Size :11160×765×3mm Weight: 3.15kg Min order:10 pcs Lead time : 15days OEM:Available Original Region:China Maximum power:18.3 Panel Efficiency:21-22.5% Soalr cell :A-grade Lead Time:15 days Sample:Not free
Learn More
